Wedge Wire Screen Filter

Incoming material first meets the upper edges of the Wedge Wire Screen Filter. Spacing between those edges determines the chosen filtration level, available from 0.02mm through 10mm. Once smaller matter crosses an inlet, the route enlarges because each V-profile flank moves away from its neighbour. Wider discharge space helps prevent deep lodging and promotes leakage. Structural support comes from rods positioned behind the active rows. Full welds secure each junction, producing a stable filter element with a smooth working side and high open area. Purchasers may choose 304 or 316L stainless steel, specify a custom format, and apply the element in petroleum, chemical, food-and-beverage, or water-treatment systems.

• Retention occurs at entry edges, keeping collected matter outside the profile depth.

• Enlarged discharge corridors create more space immediately after an inlet.

• Rear rods carry the active array without covering its working side.

• Complete welds stabilize every crossing between profiles and backing members.

• Wear resistance, corrosion resistance, and high open area are included product traits.

• The Wedge Wire Screen Filter supports custom specification within the available construction data.

• Petroleum filters needing retention at an exposed stainless inlet face.

• Chemical-process elements selected for a corrosion-resistant metal option.

• Food-and-beverage screening that uses a smooth contact side.

• Water-treatment equipment requiring an opening range between 0.02mm and 10mm.

Quality management is strict and the inspection system is complete. Finished items are checked before release, and unqualified products are not allowed to enter the market. This control principle matters for a filter whose working performance depends on profile alignment, welded intersections, and continuous openings. The company follows an integrity-based approach to every customer and treats stable product quality as the basis for long-term cooperation.
